Epson SureColor S9170
64" Eco-Solvent 11-Color Printer
MSRP: $ 28,595.00
Our Price: $ 26,595.00
Savings: $ 2,000.00
Product Code: SCS9170PE
Our most popular solvent
printer just got better.
Expand your perception of what a solvent printer can be. Offering the same extreme color gamut Epson is known for, the SureColor S9170 delivers up to 99.5% of PMS Formula Guide Solid Coated (2022 Edition) Guide. With an 11-color ink set including Red, Orange and an all-new Green, you’ll be able to faithfully reproduce virtually any color for your customers. Plus, these inks provide extremely fast dry times, allowing for same-day lamination. The SureColor S9170 features a PrecisionCore TFP printhead with an integrated temperature sensor control for reliable image quality and consistent color—job to job, panel to panel. Showcasing the latest generation of innovative Epson technology, it’s the first—ever—user-replaceable printhead in its class3, saving you time and hassle. Created to shift expectations, the SureColor S9170’s sleek, compact, modern design sets it apart—it’s like nothing we've built before.
Features and Benefits
Class-leading image quality — offers the same extreme color gamut Epson is known for; reach up to 99.5% of PMS Formula Guide Solid Coated (2022 Edition) Guide
Game-changing 11-color UltraChrome® GS3 ink set — expanded color gamut with Red, Orange and an all-new Green Ink; extremely fast dry times for same-day lamination
Sleek and compact — features an all-new precise and efficient footprint
Incredible speed and performance — built with the latest generation PrecisionCore® Micro TFP® printhead
Save time and hassle — first-ever user-replaceable solvent printhead in its class
White Ink adds versatility and enhances colors — opaque White Ink can be used on clear or dark substrates
Versatile ink — mix and match ink sizes; 800 mL or 1,500 mL
Easy to maintain — automatic daily printhead maintenance
Advanced software — simple integration to Epson Cloud Solution PORT printer monitoring system
World-class service and support — 1-year limited warranty included for your peace of mind
Specifications
Printing Technology PrecisionCore Micro TFP printhead featuring Nozzle Verification Technology and variable-sized droplet control
Ink Type UltraChrome GS3 Ink; 11-color
Ink Configuration C, M, Y, K, Lc, Lm, Lk, Or, R, G, W or Cl
Nozzle Configuration 9600 nozzles; 800 nozzles x 10 colors, 1,600 nozzles x 1 color (White)
Maximum Resolution 1200 x 1200 dpi
INK
Ink Pack Fill Volume 800 mL or 1.5 L
Ink Case Ink Supply Unit
*Printer is designed for use with Epson ink packs only, not third party ink systems
MEDIA HANDLING
Paper Path Single Roll
Paper Feed Method Friction Feed
Maximum Roll Diameter 9.84" (250 mm)
Maximum Roll Weight 99.21 lb (45 kg)
Maximum Reel Diameter 9.84" (250 mm)
Paper Width (Roll) 11.81" to 64"
Paper Thickness (Roll) Less than 1 mm
OPERATING SYSTEMS SUPPORTED
Windows® 8.1 x64 or later, macOS® 10.7 or later
Epson Edge® Print Pro Minimum PC Requirements:
Intel Core® i3 3.0 GHz CPU or faster, 8GB RAM or more, 50GB HDD or more (available during installation), DVD-ROM or Internet connection
ONYX® Go Plus Minimum PC Requirements:
Windows 10 Pro x64 or Windows 11 Pro x64, Intel or
AMD multi-core CPU, 16GB RAM or more (32-64GB
recommended), 1280x1024 minimum display, 250GB HDD or more, internet connection
GENERAL
Control Panel 4.3" Optical Touch Color LCD
Weight and Dimensions (W x D x H)
Dimensions (Printing): 102.2" x 39.2" x 102.2"
Dimensions (Stowed): 107.9" x 29.9" x 45.1"
Weight: 754 lb
Acoustic Noise Level
Sound Power Level: Not greater than 7.9 B(A)
Sound Pressure Level: Not greater than 60.5 dB(A)
Temperature
Operating: 59 ˚F to 95 ˚F
Operating (recommended): 68 ˚F to 89 ˚F
Storage: -4 ˚F to 104 ˚F (-20 ˚C to 40 ˚C)
Relative Humidity
Operating: 20% – 80% (no condensation)
Operating (recommended): 40% – 60% (no condensation)
Storage: 5% – 85% (no condensation)
Safety Standards
USA and Canada (NRTL Certified, CSA/UL 62368-1)
Compliant with Class A requirements USA (FCC),
Canada (ICES-003)
Electrical Requirements
Printer requires two 110 V outlets
Voltage:
#1 AC 100 - 120 V/200 - 240 V (50/60 Hz)
#2 AC 100 - 120 V/200 - 240 V (50/60 Hz)
Rated Current:
#1 12 A/10 A
#2 12 A/10 A
Power Consumption
Operating: Approximately 1190 W
Ready: Approximately 500 W
Sleep: Approximately 3.4 W
Power Off (Stand by): Approximately 0.3 W
Country of Origin China
Game Changing 11-Color
UltraChrome GS3 Ink Set
• The Epson S9170 continues the legacy of ultra-high image quality established by the SureColor S80600 and adds a new green ink for even higher image quality - redefining customer expectations of what a signage printer can do
• Metallic Silver has been replaced, and customers will still have the choice to use White ink or have cleaning solution in the 11th channel
• White ink circulation system to minimize risks associated with white ink printing
• Improved ink delivery system creates more accurate dot placement
• First solvent ink technology to offer Same Day Lamination
Mix and match ink sizes per color... 800 mL or 1,500 mL
First-Ever User-Replaceable
Solvent Printhead in its Class
No Special Tools Required
Replacement within 1 hour
-
Customers can replace print head and perform automatic adjustments through software
-
Active Epson Cloud Solution PORT connection and plan required
-
Ink Discharge Before Replacement
-
Physical Replacement
-
Automatic Print Head Software Adjustment
Unmatched Productivity Workflow
Epson Edge Print Pro
Intuitive Print Software
• Adobed PDF Print Engine for outstanding graphic file compatibility and RIP processes
• Powerful color management technology in an easy-to-use and intuitive workflow
• Job layout and nesting controls to increase productivity and minimize media waste
• Hot-Folder support for simply drag & drop printing
• Boost workgroup productivity with print server functionality that supports network printing from Windows clients
Onyx Bundle
Industry Leading RIP Bundle
• Includes 1-year cloud-based subscription
• Unlimited roll-to-roll cutter support
• Two active printers includes (Lvl 1 & 2)
• Color management tools included
• Production tools included
• Continuous upgrades and updates included while subscription is active
Epson Cloud Solution PORT
Remote Monitoring of Your Printing
• Cloud-based, secure and encrypted print activity reporting
• View dashboards of your printing, printer utilization, up-time, and more from any connected device
• Live information to optimize your printing efficiency
• Job Accounting to provide greater insight to manage your business
• Epson support with fast, remote troubleshooting
• https://www.epson.com/PORT
